Graphite sealant | fire resistant graphite sealant

application

high-pressure graphite sealant for fire sealing:

• openings for pipe penetrations:
  – PE/PP/PVC ≤ Ø125mm
  – PP-R ≤ Ø110mm
  – PP-MD ≤ Ø110mm
  – PP-MX ≤ Ø110mm
  – aluPE-X ≤ Ø75mm
  – PE-Xa ≤ Ø32(54)mm
  – copper ≤ Ø76mm
  – steel ≤ Ø219mm
• openings for cable penetrations:
  – cable trays ≤ Ø500mm: only seal off; coat back is NOT required!
  – cables + bundles Ø 121mm
• this product has been tested + certified for green buildings

downloads

go to the downloads page or click:

• declaration of performance (DoP)
• technical data sheet (TDS)
• charts Field of Application:
  – PE/PP/PVC
  – PP-R
  – PP-MD
  – PP-MX
  – aluPE-X
  – PE-Xa
  – copper
  – steel
  – cable trays
  – cables + bundles

certification

proven fire resistant performances related to application:

• fire resistance EI 20 up to EI 240 acc.
  – EN 1366-3, penetration seals
• classified acc. EN 13501-1+2, Euroclass
• CE marking acc. EAD 350454-00-1104 with Declaration of Performance (DoP)
  – click for more info on building products with CE marking



• acoustic performances, 30 dB up to 60 dB:
  – structural joints
• environmental performances eg:
  – BREEAM + LEED v4 (product credits)
  – Indoor Air Comfort
  – French VOC + CMR
  – EMICODE
  – AgBB + Blue Angel
  – Belgian Regulation

Firetect, it’s a system !

• Firetect is a fire rated system
• fully interchangeable, easy application
• compact product range with wide Field of Application

principle details

click below hyperlinks:

• plastic pipes in constructive element:
  – PE + PP + PVC in walls
  – PE + PP + PVC in floors

  – PP-R in walls
  – PP-R in floors

  – PP-MD in walls
  – PP-MD in floors

  – PP-MX in walls
  – PP-MX in floors

  – aluPE-X in walls + floors; pipe insulation: synthetic rubber
  – aluPE-X in walls; pipe insulation: glass wool or rock wool
  – aluPE-X in floors; pipe insulation: glass wool or rock wool

  – PE-Xa in walls
  – PE-Xa in walls; pipe insulation: polyolefin rubber
  – PE-Xa in floors; pipe insulation: polyolefin rubber

• metal pipes in constructive element:
  – copper in walls + floors
  – copper in walls; pipe insulation: synthetic rubber or rock wool
  – copper in walls; pipe insulation: glass wool or rock wool
  – copper in floors; pipe insulation: glass wool or rock wool

  – steel in walls + floors
  – steel in walls + floors; pipe insulation: synthetic rubber
  – steel in walls; pipe insulation: glass wool or rock wool
  – steel in floors; pipe insulation: glass wool or rock wool
  – steel in walls + floors; pipe insulation: PIR

• cables in constructive element:
  – cable trays in walls + floors
  – cables + bundles in walls + floors

product specifications
